The REDARC DPS1225 is a 12V, 25A DC Power Supply that provides regulated power for load requirements such as lamps, radios, computers, and more from a 12V automotive power system.
Info
The REDARC DPS1225 is a 12V, 25A DC Power Supply that provides regulated power for load requirements such as lamps, radios, computers, refrigerators, TVs, and more from a 12V automotive power system.
Perfect for sensitive loads
The DC Power supply has a wide input voltage range (9-32V) and generates little electric noise, which enables the unit to power hi-tech radio systems without interference.
Robust and flexible installation option
It is fully encapsulated in REDARC’s silicone elastomer and can be externally mounted on the vehicle and used in marine applications. Users benefit from built-in surge protection and reverse polarity. Additional benefits include more efficiency with regulated output power and improved functionality.
Specifications
| Output Voltage | 12VDC |
| Output Current Rating (Cont.) | 25A |
| Input Fuse Rating | 40A |
| Output Fuse Rating | 40A |
| Length (in) | 5.91 |
| Width (in) | 4.72 |
| Height (in) | 1.46 |
| Warranty | 2 Years |
| Weight (lb) | 1.5 |
